Category | Integrated Circuits (ICs) |
Family | Logic - Gates and Inverters |
Series | 74HC |
Packaging | Tape & Reel (TR) |
Logic Type | Inverter |
Number of Circuits | 6 |
Number of Inputs | 6 |
Voltage - Supply | 2 V ~ 6 V |
Current - Quiescent (Max) | 2µA |
Current - Output High, Low | 5.2mA, 5.2mA |
Logic Level - Low | 0.5 V ~ 1.8 V |
Logic Level - High | 1.5 V ~ 4.2 V |
Max Propagation Delay @ V, Max CL | 14ns @ 6V, 50pF |
Operating Temperature | -40°C ~ 125°C |
Mounting Type | Surface Mount |
Supplier Device Package | 14-SO |
Package / Case | 14-SOIC (0.154", 3.90mm Width) |
