Datasheets | 6N137, HCPL2601,11,30,31 |
---|---|
Category | Isolators |
Family | Optoisolators - Logic Output |
Packaging | Tube |
Number of Channels | 1 |
Inputs - Side 1/Side 2 | 1/0 |
Voltage - Isolation | 2500Vrms |
Common Mode Transient Immunity (Min) | 15kV/µs |
Input Type | DC |
Output Type | Open Collector |
Current - Output / Channel | 50mA |
Data Rate | 10Mbps |
Propagation Delay tpLH / tpHL (Max) | 75ns, 75ns |
Rise / Fall Time (Typ) | 50ns, 12ns |
Voltage - Forward (Vf) (Typ) | 1.4V |
Current - DC Forward (If) (Max) | 50mA |
Voltage - Supply | 4.5 V ~ 5.5 V |
Operating Temperature | -40°C ~ 85°C |
Mounting Type | Through Hole |
Package / Case | 8-DIP (0.300", 7.62mm) |
Supplier Device Package | 8-DIP |
