Datasheets | 1N4001 - 1N4007 Datasheet |
---|---|
Series | - |
Diode Type | Standard |
Voltage - DC Reverse (Vr) (Max) | 1000V (1kV) |
Current - Average Rectified (Io) | 1A |
Voltage - Forward (Vf) (Max) @ If | 1.1V @ 1A |
Speed | Standard Recovery >500ns, > 200mA (Io) |
Reverse Recovery Time (trr) | 2µs |
Current - Reverse Leakage @ Vr | 5µA @ 1000V |
Capacitance @ Vr, F | - |
Package / Case | DO-204AL, DO-41, Axial |
Supplier Device Package | DO-41 |
Operating Temperature - Junction | -55°C ~ 150°C |
Other Names | 1N4007MSCT |
