Datasheets | FGL60N100BNTD |
---|---|
IGBT Type | NPT and Trench |
Voltage - Collector Emitter Breakdown (Max) | 1000V |
Current - Collector (Ic) (Max) | 60A |
Current - Collector Pulsed (Icm) | 120A |
Vce(on) (Max) @ Vge, Ic | 2.9V @ 15V, 60A |
Power - Max | 180W |
Input Type | Standard |
Gate Charge | 275nC |
Td (on/off) @ 25°C | 140ns/630ns |
Test Condition | 600V, 60A, 51 Ohm, 15V |
Reverse Recovery Time (trr) | 1.2µs |
Package / Case | TO-264-3, TO-264AA |
Mounting Type | Through Hole |
Supplier Device Package | TO-264 |
