Datasheets | IRF3708 |
---|---|
FET Type | MOSFET N-Channel, Metal Oxide |
FET Feature | Standard |
Drain to Source Voltage (Vdss) | 30V |
Current - Continuous Drain (Id) @ 25°C | 62A (Tc) |
Rds On (Max) @ Id, Vgs | 12 mOhm @ 15A, 10V |
Vgs(th) (Max) @ Id | 2V @ 250µA |
Gate Charge (Qg) @ Vgs | 24nC @ 4.5V |
Input Capacitance (Ciss) @ Vds | 2417pF @ 15V |
Power - Max | 87W |
Mounting Type | Surface Mount |
Package / Case | DPak (2 Leads + Tab), SC-63 |
