Datasheets | STM8S207,208xx |
---|---|
Other Related Documents | STM8S207MB View All Specifications |
Product Training Modules | STM8S |
Design Resources | Development Tool Selector |
Featured Product | Flasher Series of Production Tools |
Standard Package | 90 |
Family | Embedded - Microcontrollers |
Series | STM8S |
Core Processor | STM8 |
Core Size | 8-Bit |
Speed | 24MHz |
Connectivity | I²C, IrDA, LIN, SPI, UART/USART |
Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
Number of I/O | 68 |
Program Memory Size | 128KB (128K x 8) |
Program Memory Type | FLASH |
EEPROM Size | 2K x 8 |
RAM Size | 6K x 8 |
Voltage - Supply (Vcc/Vdd) | 2.95 V ~ 5.5 V |
Data Converters | A/D 16x10b |
Oscillator Type | Internal |
Operating Temperature | -40°C ~ 85°C |
Package / Case | 80-LQFP |
Supplier Device Package | * |
Other Names | 497-8952 STM8S207MBT6B-ND |
