74HC573-SOP20

  • Thương hiệu: NXP
  • Loại: Logic
  • Mã sản phẩm: C-H6-C13

Giá bán: 6,000₫

Datasheets74HC(T)573Product Training ModulesLogic PackagesCategoryIntegrated Circuits (ICs)FamilyLogic - LatchesSeries74HCPackaging  Tape & Reel (TR)  Logic TypeD-Type Transparent LatchCircuit8:8Output TypeTri-StateVoltage - Supply2 V ~ 6 VIndependent Circuits1Delay Time - Propagation14nsCurrent - Output High, Low7.8mA, 7.8mAOperating...
  • Giao hàng
    Giao hàng
    Miễn phí giao hàng nội thành Tp. HCM với đơn hàng trên 500'000VNĐ
  • Sản phẩm
    Sản phẩm
    Cam kết hàng mới 100%
  • Đổi trả
    Đổi trả
    Chi tiết trong phần bảo hành
  • Hỗ trợ
    Hỗ trợ
    Bán hàng: 0981 276 209
    Kỹ thuật: 0823 893 984

Chia sẻ

Datasheets

74HC(T)573

Product Training Modules

Logic Packages

Category

Integrated Circuits (ICs)

Family

Logic - Latches

Series

74HC

Packaging

Tape & Reel (TR)

Logic Type

D-Type Transparent Latch

Circuit

8:8

Output Type

Tri-State

Voltage - Supply

2 V ~ 6 V

Independent Circuits

1

Delay Time - Propagation

14ns

Current - Output High, Low

7.8mA, 7.8mA

Operating Temperature

-40°C ~ 125°C

Mounting Type

Surface Mount

Package / Case

20-SOP

Supplier Device Package

20-SOP

Online Catalog

74HC
