| Datasheets | CD4013B Types |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Flip Flops |
| Series | 4000B |
| Function | Set(Preset) and Reset |
| Type | D-Type |
| Output Type | Differential |
| Number of Elements | 2 |
| Number of Bits per Element | 1 |
| Frequency - Clock | 24MHz |
| Max Propagation Delay @ V, Max CL | 90ns @ 15V, 50pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 6.8mA, 6.8mA |
| Voltage - Supply | 3 V ~ 18 V |
| Current - Quiescent | 4µA |
| Input Capacitance | 5pF |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP (0.300", 7.62mm) |
- Liên hệ:
- Bán hàng: 0981 276 209 - Kỹ thuật: 0823 893 984
-
Tin tức:
CD4013-DIP14
- Thương hiệu: Khác
- Loại: Khác
- Mã sản phẩm: A-9-10
Giá bán: 5,000₫
DatasheetsCD4013B TypesCategoryIntegrated Circuits (ICs)FamilyLogic - Flip FlopsSeries4000BFunctionSet(Preset) and ResetTypeD-TypeOutput TypeDifferentialNumber of Elements2Number of Bits per Element1Frequency - Clock24MHzMax Propagation Delay @ V, Max CL90ns @ 15V, 50pFTrigger TypePositive EdgeCurrent -...
-
Giao hàng
Miễn phí giao hàng nội thành Tp. HCM với đơn hàng trên 500'000VNĐ -
Sản phẩm
Cam kết hàng mới 100% -
Đổi trả
Chi tiết trong phần bảo hành -
Hỗ trợ
Bán hàng: 0981 276 209
Kỹ thuật: 0823 893 984
